8AI/2DO IoT Modbus/SNMP/MQTT Ethernet Remote I/O

8ch analog input(voltage or current)/2ch digital outputProtocols:MQTT(TLS),SNMP,Modbus TCP,RESTful API,ASCIIGCL to perform basic logic control rulesPeer-to-Peer function to map I/O statusCloud access: Data update to AzureBuilt-in web serverWatchdog timer to recover the system

Analog Input - Channels: 8 | Analog Input - Input Range: ±0.15 V ±0.5 V, ±1 V, ±5 V, ±10 V, ±20 mA, 0~20 mA, 4~20 mA, 0~0.15V, 0~0.5 V, 0~1 V, 0~5 V, 0~10 V | Analog Input - lnput Type: V, mV, mA | Analog Input - Resolution(Bits): 16-bit | Analog Input - Sampling Rates(S/s): 100 S/s (sum) | Communications - Interface: Ethernet | Environment - Isolation Voltage: 2,000 VDC | Environment - Operating Temperature: -40~70 °C (-40~158 °F) | General - Connectors: 1 x RJ45, 1 x 13-pin plug-in screw terminal, 1 x 9-pin plug-in screw terminal | General - Protocol: Modbus/TCP, TCP/IP, UDP, HTTP, DHCP, MQTT, SNMP, ASCII command | Isolated Digital Output - Channels: 2 | Isolated Digital Output - Output Type: Sink | Isolated Digital Output - Output Voltage: 0~30 VDC | Isolated Digital Output - Sink Current: 100 mA max./channel | Power Requirements - Input Voltage: 10~30 VDC

• Model: ADAM-6017-D
