The Advantech AIMB-785 is a feature-rich industrial-grade ATX motherboard built to support Intel® 6th and 7th Gen Core™ i7/i5/i3, Pentium®, and Celeron® processors on the LGA1151 socket with the Q170 chipset. Tailored for industrial environments, it delivers enhanced visual output, robust expansion, and dependable connectivity.

Key Features:

• Supports Intel® 6th/7th Gen Core™ i7/i5/i3, Pentium®, and Celeron® CPUs

• Q170 chipset with LGA1151 socket

• 4 x DDR4 DIMM slots, up to 64 GB (1866/2133/2400 MHz)

• Triple display support: 1 x VGA, 2 x DVI-D

• Dual Gigabit Ethernet (GbE) LAN ports

• SATA RAID 0/1/5/10 and USB 3.0 for high-speed storage and peripherals

• Expansion slots for custom industrial configurations

• Supports Intel® vPro, AMT 11.0, and TPM technologies

Designed for reliability and long-life support, the AIMB-785 is ideal for automation, control, and embedded computing applications with legacy integration needs.
