The Honeywell CC-PWRB01 is a robust redundant 24 V DC power system for the Experion Series-C (C300) control cabinet. It features dual 20 A power supplies plus an integrated 24 V battery backup assembly—designed to provide up to 30 minutes of uninterrupted power at full load during AC power outages. Housed in a durable metal chassis, it includes alarm signaling and easy field maintenance, making it a reliable solution for critical industrial automation applications.

Key Specifications – Honeywell CC-PWRB01

• Configuration: Dual 20 A 24 V DC power supplies for full redundancy

• Battery Backup: Provides 30 minutes of 24 V load support at 20 A during mains failure

• Input Voltage: 100–240 VAC, 47–63 Hz

• Output Voltage:

  • 25–26 VDC when AC is present

  • 24–25 VDC when running on battery


• Features:

  • Blade-style modular design for quick swap-out under load

  • Alarm outputs for system monitoring

  • Supports separate AC sources for each supply

• Power Handling: Sustains up to 20 A continuously

• Battery Maintenance: Up to 30 minutes hold-up when AC fails


• Built for Series-C:

  • Compact and space-efficient

  • Compatible with standard field and RAM battery connections


• Form Factor:

  • Metal enclosure with eight top connectors (power, RAM firmware battery, alarm)


• Country of Origin: USA
