The Honeywell 2MLI‑D24A is a 32‑point DC24 V digital input module (sink/source), photo‑coupled isolated, ideal for industrial MasterLogic‑200 PLC systems.

Model: 2MLI‑D24A

✅ Applications:

• Field signal acquisition for MasterLogic‑200 PLCs

• Industrial automation systems

• Machine controllers, relays, sensors

• OEM panels, retrofits, infrastructure control

🔍 Key Features:

• Points: 32 digital inputs (sink/source)

• Rated Voltage: DC 24 V

• Input Current: Approx. 4 mA per point

• Voltage Range: DC 20.4–28.8 V (≤5 % ripple)

• Response Time (On → Off/Off → On): Programmable 1–100 ms (default 3 ms)

• Isolation: Photo‑coupler, 560 Vrms withstand

• Power Draw: 50 mA nominal

• Connector: 40‑pin terminal block (M3 screw)

• Dimensions: 2.2 cm × 12.4 cm × 12.6 cm (approx.)

• Weight: ~0.10 kg (100 g)

• Operating Temp: 0 °C to 55 °C

• Certifications: CE, photo‑coupler isolation, industrial grade
