Honeywell 2MLL‑EFMF | Fiber-Optic Ethernet Module | MasterLogic‑200 PLC
by Honeywell
Sale
Original price
Rs. 113,356.65
Original price
Rs. 113,356.65
-
Original price
Rs. 113,356.65
Original price
Rs. 113,356.65
Current price
Rs. 40,810.05
Rs. 40,810.05
-
Rs. 40,810.05
Current price
Rs. 40,810.05
The Honeywell 2MLL‑EFMF is a fiber-optic 100 Mbps Fast Ethernet module (SC connector) for MasterLogic‑200 PLCs. Supports peer-to-peer, MODBUS TCP, up to 2 km range.
Model: 2MLL‑EFMF
✅ Applications:
-
Provides fiber-optic Ethernet (100Base-FX) for MasterLogic‑200/200R systems
-
Ideal for EMI-prone or long-distance communication (up to 2 km)
-
Supports peer-to-peer PLC networking, Experion integration via MLDP, MODBUS TCP/IP
🔍 Key Specifications:
| Feature | Details |
|---|---|
| Ethernet Speed | 100 Mbps (100Base-FX fiber-optic) |
| Media & Connector | 62.5/125 µm multimode fiber with SC connector; up to 2 km transmission |
| Nodes Supported | Up to 64 nodes per fiber segment |
| Protocol Support | TCP/IP, UDP/IP, peer-to-peer, MLDP, MODBUS TCP, SoftMaster I/F |
| Power Consumption | 410 mA typical, 630 mA peak @ 24 VDC |
| Weight | ~120 g |
| LED Indicators | RUN, I/F, HS, P2P, PADT, PC, ERR, TX, RX, 10/100 speed |
| Diagnostics | Supports network auto-scan, ping test, frame/link monitoring |
| Operating Conditions | 0–55 °C ambient, compatible with industrial rack environments |
SKU 2MLL-EFMFB
