The Honeywell 8C-SDOX01 is a rugged, coated relay extension board within Honeywell’s Series 8 Experion-LX I/O family. Designed to convert Honeywell digital output modules (DO IOMs) into isolated dry-contact relay outputs, it offers 32 Form-C SPDT channels with LED status indicators, enabling reliable interfacing with high-voltage or high-current devices. Engineered for harsh environments, it supports hot-swap insertion/removal and maintains signal isolation and durability in mission-critical control systems.Honeywell 8C‑SDOX01 DO Relay Extension: 32 isolated Form‑C relays, 250 VAC/125 VDC, coated for harsh environments, hot‑swap enabled, Class I Div 2/Zone 2 rated.

Key Specifications

• Model / Part Number: 8C‑SDOX01 — Digital Output Relay Extension IOTA (coated)

• Output Channels: 32 Form‑C relay contacts (SPDT), integrated with DO I/O modules

• Contact Ratings:

  • 5 A @ 125/250 VAC (resistive)

  • 3 A @ 30 VDC resistive / 2 A inductive (PF 0.4)

• Isolation: 1,500 VAC RMS channel-to-channel and channel-to-logic

• Coating & Durability: Conformal-coated (G3) for moisture, dust & chemicals

• Module Removal/Insertion: Hot-swap capable under power

• Environmental Specs:

  • Operating: –40 °C to +70 °C

  • Storage: –40 °C to +85 °C

  • Humidity: 5–95% non-condensing

• Dimensions & Weight: Approx. 15″ IOTA format; module weight ~1 kg

• Certifications:

  • Class I Div 2 / Zone 2, IECEx Ex ec nC IIC T4 Gc (unique to SDOX01)
