10.1" WSVGA, 64MB, 128MB(NAND), Serialx3, Ethernet

ARM9™ 32-bit RISC processor with 64 MB SDRAM working memorySupports over 500+ PLC industrial communication protocolsBackup memory 128KB for retaining critical data or parameterSupports the HMINavi Designer development tool free on Windows 10Supports HMINavi Runtime data downloads through Serial, Ethernet, USB portNo limitation on the internal I/Os points used for variety applicationEasy to switch one application to different LCD sizes in secondsSupports operation in both landscape and portrait modePanel mount design ensures easy installation and IP66-rated front panel

Environment - Ingress Protection: Front Panel IP66 | Environment - Operating Temperature: -15~65 °C (5~149 °F) | Environment - Relative Humidity: 5~95% RH (non-condensing) | Environment - Vibration Protection: 1 Grms, random | General - Connectors: 1 x RJ45, 1 x DB9 female | General - Programming Language: HMINavi Designer | General - Protocol: 500+ PLC Drivers | General - Rated Voltage: 24 VDC (±10%) | Hardware - Certification: CE, FCC class A, UL-61010 | Hardware - CPU: ARM9™ 32-bit RISC processor | Hardware - LAN: 1 x 10/100 Mbps | Hardware - Memory: 1 x 64 MB SDRAM | Hardware - OS Support: RTOS | Hardware - Power Consumption: 20 W @ 24 VDC | Hardware - Power Requirement: 24 VDC ±10% | Hardware - Storage: 1 x 128M NAND Flash | I/O Interface - Serial Ports: 1 x RS-232, 1 x RS-422/485, 1 x RS-485 | I/O Interface - USB Ports: 1 x USB (Host), 1 x USB (Client) | LCD Display - Backlight Life (hrs): 20,000 | LCD Display - Display Size: 10.1" | LCD Display - Luminance (cd/m2): 350 | LCD Display - Max. Resolution: 1024 x 600 | Mechanical - Dimension (W x H x D): 270.1 x 212.1 x 43.4 mm | Mechanical - Enclosure: PC + ABS | Mechanical - Mounting: Panel | Mechanical - Weight (Net): 1.1 kg (2.43 lb) | Touchscreen - Touch Type: 4-wire resistive

• Model: WOP-210K-NAE
